Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-DM-XD1406C
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

Split Type Elevator Door Machine Device With AC Variable Frequency Control

Description
Name: Split Type Door Machine Device Voltage: AC220V
Applicable: Elevator Equipment Business Type: Manufacturer
Original: CHINA Packing: Wooden Box
Opening Way: Two-Speed Door Operator Opening Width: 700-1200mm
Model: Split Type Door Machine Device Product: Split Type Door Machine Device
Highlight:

AC220V Elevator Door Device

,

Split Type Elevator Door Machine

,

AC Variable Frequency Control Door Operator

Split Type Door Machine Device With AC Variable Frequency Control


Model Name: SN-DM-XD1406C

Split type door machine device


Description

AC variable frequency control
Special interface is connected with elevator system for variable frequency

Operating voltage in variable frequency mode:AC 220V
Asynchronous door vane, synchronous belt drive
The car top and straight beam installations are optional

Car door lock function





Mounting dimensions:



Net door opening width JJ 700 800 900 1000 1100 1200
L 1460 1660 1860 2060 2260 2460





 Split Type Elevator Door Machine Device With AC Variable Frequency Control 0


Model Name: SN-DM-XD1421

Split type door machine device



Permanent magnet variable frequency and voltage regulation control

Operating voltage AC220V
Asynchronous door vane, synchronous belt drive

Car top or front wall installation optional
Fully digitized close-loop control
Car door lock function





Mounting dimensions:



Net door opening width JJ 700 800 900 1000 1100 1200
L 1460 1660 1860 2060 2260 2460



Split Type Elevator Door Machine Device With AC Variable Frequency Control 1



Split Type Elevator Door Machine Device With AC Variable Frequency Control 2



Split Type Elevator Door Machine Device With AC Variable Frequency Control 3



Split Type Elevator Door Machine Device With AC Variable Frequency Control 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
