600~1400mm Jj Center Opening Landing Door Device For Elevator Parts

Customer Reviews
Service is people-oriented and honesty is the most attractive. It's a pleasure to cooperate with you

—— Millay

I'm Online Chat Now

600~1400mm Jj Center Opening Landing Door Device For Elevator Parts

600~1400mm Jj Center Opening Landing Door Device For Elevator Parts
600~1400mm Jj Center Opening Landing Door Device For Elevator Parts
600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 600~1400mm Jj Center Opening Landing Door Device For Elevator Parts

Large Image :  600~1400mm Jj Center Opening Landing Door Device For Elevator Parts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-DM-OCM108
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

600~1400mm Jj Center Opening Landing Door Device For Elevator Parts

Description
Name: Center Opening Landing Door Device Door Opening: 600mm-1400mm
Voltage: AC220V Business Type: Manufacturer
Warranty Time: 12 Months Transportation: Sea Delivery
Applicable: Elevator Equipment Opening Way: Centre
Model: Center Opening Landing Door Device Type: Center Opening Landing Door Device

600~1400mm Jj Center Opening Landing Door Device For Elevator Parts

Product Description

Feature:
Safe and reliable:
The door hanger has a safety hook to prevent collision and fall off, passed 45kg soft pendulum test, which conforms to GB/T7588.1/2 standard requirement.

Self-closing type:
Common weight or common spring self-closing types are optional.

Multiple certificates:
The door lock has passed the National Type Test Certification, CE Certification, and EAC Certification. The standard protection level is IP20, while the high-end version offers IP66. The landing door device can achieve IP23 protection by adding an extended dust cover (the door lock remains IP20), or you may opt for a high-end door lock to reach IP66 protection level.

Applicable voltage:
Door lockvoltages ≤ AC230V,≤ DC110V.

Floor height range:
Standard floor height ≥ HH+500, lowest floor height HH+350.



Specification
JJ
600
650
700
750
800
850
900
950
1000
A1L
1220
1320
1420
1520
1620
1720
1820
1920
2020
A2L
175
200
225
250
275
300
325
350
375
H1
1340
1340
1340
1340
1340
1340
1340
1540
1540
JJ
1050
1100
1150
1200
1250
1300
1350
1400
A1L
2120
2220
2320
2420
2520
2620
2720
2820
A2L
400
425
450
475
500
525
550
575
H1
1540
1740
1740
1740
1840
1840
1840
1840



600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 0



600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 1



600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 2



600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 3



600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 4600~1400mm Jj Center Opening Landing Door Device For Elevator Parts 5



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
