Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine

Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine
Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine

Large Image :  Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: elevator traction machine
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: $500~1200
Packaging Details: container
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine

Description
Name: Gearless Elevator Machine Max.shaft Load: 6000kg
Speed: 1.0M/S Roping: 2:1
Votage: 380V Brake Voltage: DC110V
Applicable: Elevator Equipment Warranty Time: 12 Months
Model: Gearless Elevator Machine Type: Gearless Elevator Machine
High Light:

elevator traction machine

,

lift traction machine

Permanent magnet synchronous gearless anti explosion traction machine


Voltage:380V
Brake voltage:DC 110V
Encoder application:1387
Max. shaft load:6000kg
Load 2:1:800kg-1600kg



Model Type Load(kg) Speed
(m/s)
Sheave
(mm)
Rope and Pitch(mm) Current
(A)
Rated speed
(rpm)
Frequency
(Hz)
Torque
(Nm)
Power
(kw)
Roping
2:1 4:1
SN-PBYTW24-2 1mSC-80 800   1.0 400 10*4-16 12.8 96 16 670 5.5
2mSC-80   1500 1.0 400 10*4-16 24.9 192 32 / 11
1mSC-100 1000   1.0 400 10*5-16 15.7 96 16 670 6.7
2mSC-100   2000 1.0 400 10*5-16 31.3 192 32 / 13.4
1mSC-125 1250   1.0 400 10*6-16 19 96 16 670 8.3
2mSC-125   2500 1.0 400 10*6-16 38 192 32 / 16.7
1mSC-160 1600   1.0 400 10*8-16 24.5 96 16 1100 11
2mSC-160   3200 1.0 400 10*8-16 49 192 32 / 2



Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine 0

Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine 1



Permanent Magnet Gearless Elevator Machine / Anti Explosion Elevator Traction Machine 2



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
