Product Details:
|
| Load: | 630~800kg | Speed: | 1.0~1.75m/s |
|---|---|---|---|
| Model: | Elevator Parts | Type: | Gearless |
| Warranty Time: | 12 Months | Transportation: | Sea Delivery |
| Product Name: | Gearless Traction Motor | Applicable: | Elevator Equipment |
| Product: | Gearless Traction Motor | Name: | Gearless Traction Motor |
| Highlight: | 800kg Load Gearless Traction Motor Machine,1.75m/s Gearless Traction Motor Machine,ISO9001 Gearless Traction Motor Machine |
||
Elevator Lift Parts Gearless Traction Motor Machine For Traction System
1.75m/S 800kg Load Gearless Traction Motor Machine ISO9001 For Lift
Using traditional drum brake, mature and reliable technology.convenient adjustment and widely used
Motor with inter rotor structure, low noise, low vibration, smooth operation,high power factor, with quick response time and high rlablity
Adapt iferent inverters, position sensors
Large loading capacity. suitable for the mdermization of existing elevator
| Type | SN-TM103-04.1/1.0 | SN-TM103-04.2/1.0~1.75 | ||
| Traction Ratio | 1:1 | |||
| Rated Voltage(V) | 380 | |||
| Rated Load(kg) | 630 | 800 | ||
| Max axis load(kg) | 7600 | |||
| Weight(kg) | 5500 | |||
| Rated Speed(m/s) | 1.0 | 1.0 | 1.5 | 1.6/1.75 |
| Tracion wheel diameter(mm) | Φ440 | |||
| Rope groove | 6-Φ10 | 7-Φ10 | ||
| L1(mm) | 190 | |||
| L2(mm) | 54 | |||
| L3(mm) | 407 | 427 | ||
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
