3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet

3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet
3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet

Large Image :  3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-WYJ340
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 5000 Pcs/ Month

3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet

Description
Load: 1350~4000kg Applicable Converter: 3 Phase 400V
Speed: 1.0-3.0m/s Roping: 2:1
Guide Rail: T Guide Picking/Holding Voltage: DC110V
Certificate: ISO9001 / CCC Warranty Time: One Year
Model: Elevator Traction Machine Type: Elevator Traction Machine
Product: Elevator Traction Machine
High Light:

Permanent Magnet Elevator Traction Motor

,

T Guide Elevator Gearless Traction Machine

,

Lift Traction Machine 400V

Gearless Permanent Magnet / Elevator Traction Machine 4000kg 3.0m/S



Detailed Product Description

  1. Rated capacity: 1350~4000kg
  2. Rated elevator speed: 1.0,1.5,1.75,2,2.5,3.0m/s
  3. Max. lifting height: 120m
  4. We can supply various traction machines for you
Traction ratio: 1:1,2:1
Rated capacity: 1350~4000kg
Rated elevator speed: 1.0,1.5,1.75,2,2.5,3.0m/s
Max. lifting height: 120m
Max. shaft load: 10000kg
Applicable converter: 3 phase 400V
Brake voltage: DC200V for Brake opening, and DC100V for brake holding





3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet 0



3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet 1


3 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet 23 Phase 400V T Guide Elevator Gearless Traction Machine Permanent Magnet 3

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
