Product Details:
|
Product Name: | Elevator Gearless Traction Machine | Voltage: | 380V |
---|---|---|---|
Suspension: | 2:1 | Load: | 320-450KG |
Weight: | 80kg | Max.Static Load: | 2000kg |
Applicable: | Elevator Equipment | Warranty Time: | One Year |
Model: | Elevator Gearless Traction Machine | Product: | Elevator Gearless Traction Machine |
Type: | Elevator Gearless Traction Machine | ||
High Light: | 6x6 Ropes Gearless Traction Machine,320kg Elevator Gearless Traction Machine,Commercial Gearless Lift Motor |
320~450kg Elevator Gearless Traction Machine With 6xØ6 Max Ropes
Static load:2000kg
Load:450kg
Speed:up to 0.4m/s
Sheave:120-160mm
Weight:80kg
Nominal Torque |
Short circuited torque |
Poles |
Encoder |
Nm | Nm | / | / |
125 S5-25%ED 180s/h | 140 | 16 | ERN1387 ECN1313 EI53C9.25 TS5213N2531 |
Brake | |||
EMFR DC110V/1.4A[2X125Nm] |
/ | Ropes | |||
ØD | F | Ø | n° | Pitch |
mm | mm | mm | ||
120 | 82 | 6.5 | 6 | 10 |
160 | 6 |
2:1 | Load | Ø | Ropes | Pitch | Torque | Power | RPM | Freq. | Current 220V | Current 380V | |
kg | m/s | mm | max | mm | Nm | kW | RPM | Hz | A | A | |
320 | 0.3 | 160 | 6xØ6 | 10 | 70 | 0.52 | 72 | 9.5 | 4.7 | 3.3 | |
0.4 | 160 | 6xØ6 | 10 | 81 | 0.81 | 95 | 12.7 | 5.5 | 3.9 | ||
400 | 0.3 | 160 | 6xØ6 | 10 | 103 | 0.77 | 72 | 9.5 | 7.0 | 4.9 | |
0.4 | 160 | 6xØ6 | 10 | 103 | 1.02 | 95 | 12.6 | 7.0 | 4.9 | ||
450 | 0.3 | 120 | 6xØ6.5 | 10 | 86 | 0.86 | 95 | 12.7 | 5.8 | 4.1 | |
0.4 | 120 | 6xØ6.5 | 10 | 86 | 1.14 | 127 | 16.9 | 6.9 | 5.8 |
