630kg Elevator Belt Gearless Traction Machine For Elevator Lift Component

Large Image : 630kg Elevator Belt Gearless Traction Machine For Elevator Lift Component

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	SN-MDG63

Payment & Shipping Terms:

Minimum Order Quantity:	1 Pcs
Price:	$500~1200
Packaging Details:	Wooden box
Delivery Time:	7~15 days
Payment Terms:	Western Union, T/T, L/C,Paypal
Supply Ability:	5000 Pcs/ Month

Contact Now

630kg Elevator Belt Gearless Traction Machine For Elevator Lift Component

Description

Product Name:	Elevator Gearless Traction Machine	Voltage:	380V
Suspension:	2:1	Load:	630KG
Weight:	120kg	Max.Static Load:	2000kg
Applicable:	Elevator Equipment	Warranty Time:	One Year
Model:	Elevator Gearless Traction Machine	Product:	Elevator Gearless Traction Machine
Type:	Elevator Gearless Traction Machine
High Light:	630kg Gearless Traction Motor , Elevator Belt Gearless Traction Machine , Commercial Gearless Elevator Motor

630kg Elevator Belt Gearless Traction Machine For Elevator Lift Component

Static load:2000kg
Load:630kg
Speed:up to1m/s
Sheave:85~100mm
Weight:120kg

Nominal Torque	Short circuited torque	Poles	Encoder	Belt Pulley
Nm	Nm	/	/	Width(mm)	min-max(n°)	Pitch(mm)
104 S5-40%ED 180s/h	140	16	ERN1387 ECN1313 EI53C9.25 TS5213N2531	60/55	3	65
Brake
EMFR DC110V/1.4A[2X125Nm]

2:1	Load		Ø	n°	Pitch	Torque	Power	RPM	Freq.	Current 220V	Current 380V
	kg	m/s	mm		mm	Nm	kW	RPM	Hz	A	A
	630	0.4	100	3	65	104	1.7	153	20.4	8.7	5.0
		0.5	100	3	65	104	2.1	191	25.5	11.9	7.0
		1.0	100	3	65	104	4.1	382	50.9	16.9	8.7
	630	0.4	85	3	65	88	1.7	180	24.0	7.0	6.0
		0.5	85	3	65	88	2.1	225	30.3	8.2	7.4
		1.0	85	3	65	88	4.1	449	59.9	15.0	8.0

1:1	Load		Ø	n°	Pitch	Torque	Power	RPM	Freq.	Current 220V	Current 380V
	kg	m/s	mm		mm	Nm	kW	RPM	Hz	A	A
	320	0.4	100	3	65	92	0.7	76	10.2	6.3	4.4
		0.5	100	3	65	92	0.9	95	12.7	6.3	4.4
		1.0	100	3	65	92	1.8	191	25.5	8.5	6.3
	400	0.4	85	3	65	108	1.0	90	12.0	7.3	4.4
		0.5	85	3	65	108	1.3	112	15.0	8.5	4.9
		1.0	85	3	65	108	2.5	225	30.0	10.0	7.3

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
