SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems

Large Image : SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	SN-BPM450

Payment & Shipping Terms:

Minimum Order Quantity:	1 Pcs
Price:	$500~1200
Packaging Details:	Wooden box
Delivery Time:	7~15 days
Payment Terms:	Western Union, T/T, L/C,Paypal
Supply Ability:	5000 Pcs/ Month

Contact Now

SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems

Description

Product Name:	Elevator Gearless Traction Machine	Voltage:	380Vor220V
Suspension:	2:1	Load:	320~630kg
Weight:	120kg	Max.Static Load:	2250kg
Applicable:	Elevator Equipment	Warranty Time:	One Year
Model:	Gearless Traction Machine	Product:	Gearless Traction Machine
Type:	Gearless Traction Machine
High Light:	Elevator Systems Gearless Traction Machine , Customizable Gearless Traction Machine

SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems

Type:SN-BPM450

ELEVATOR TRACTION MACHINE
Suspension	2 : 1/1:1
Voltage	380Vor220V
Pole	12
Rating	S5(25%)
INS. Class	F
IP Code	IP41
FZD15 Brake	DC110V 1.34A
Max. Static Load	2250kg
Weight	120kg

DIMENSIONS

SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems 0

TECHNICAL DATA

SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems 1

REMARK

※ The torque can be increased to 130Nm, when the speed drops to 0.4m/s.
The standard configuration of this machine does not include connection cable and manual brake release. Customers are required toprovide their own electric brake release device.
The connection cable and manual brake release are optional to provide if the customer need them.

Type:SN-ERSC

ELEVATOR TRACTION MACHINE
Suspension	2 : 1/1:1
Voltage	380Vor220V
Pole	20
Rating	S5(25%)
INS. Class	F
IP Code	IP41
FZD15 Brake	DC110V 1.34A
Max. Static Load	2250kg
Weight	100kg

DIMENSIONS

SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems 2

TECHNICAL DATA

SN-BPM450 Customizable Gearless Traction Machine For Elevator Systems 3

REMARK

※The torque can be increased to 130Nm, when the speed drops to 0.4m/s.
The standard configuration of this machine does not include connection cable and manual brake release. Customers are required toprovide their own electric brake release device.
The connection cable and manual brake release are optional to provide if the customer need them.

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
