SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts

SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts
SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts

Large Image :  SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE, ISO9001
Model Number: SN-MY07
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $500~1200
Packaging Details: Wooden box
Delivery Time: 7~15 days
Payment Terms: T.T, Western Union, Paypal, L.C
Supply Ability: 5000pcs/month
Contact Now

SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts

Description
Product Name: Elevator Traction Motor Speed: 0.5~1.75m/s
Pitch: 12 Diameter: Φ400
Rated Frequency: 12hz Load: 320-450KG
Voltage: 380V Rating: S5-40%
Brake: DC110V Model: Elevator Traction Motor
Type: Elevator Traction Motor
Highlight:

Hot Sale Gearless Traction Machine

,

12 Pitch Gearless Traction Machine

,

Elevator Lift Parts Gearless Traction Machine


 SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts

Type:SN-MY07

Speed
(m/s) 		Roping Rise(m) Motor Parameter Brake Parameter Sheave Parameter
Rated power
(kW) 		Rated Torque
(N.m) 		Rated Speed (RPM) Rated Frequency
(Hz) 		Rated Current
(A) 		Voltage
(V) 		Current (A) Voltage (V) Braking Torque (N.m) Diameter
(mm) 		nxd(mm) Pitch
(mm) 		β γ
0.5 2:1 ≤30 2 320 60 12 4.8 380 2.2 DC110 ＞1800 320 5-Φ8 12 95 30
1 ≤50 4 119 23.8 9.2
1.5 ≤75 6 179 35.8 14
1.75 ≤90 7 209 41.8 16.5
0.5 ≤30 2.5 410 60 12 6 6-Φ8 12 95 30
1 ≤50 5 119 23.8 12
1.5 ≤75 7.6 179 35.8 18
1.75 ≤90 9 209 41.8 20.5
0.5 ≤30 3.2 510 60 12 7.5 6-Φ8 12 95 30
1 ≤50 6.4 119 23.8 15
1.5 ≤75 9.5 179 35.8 22 7-Φ8
1.75 ≤90 11 209 41.8 26
0.5 2:1 ≤30 2 320 60 12 4.8 380 400 5-Φ8 12 95 30
1 ≤50 4 119 23.8 9.2
1.5 ≤75 6 179 35.8 14
1.75 ≤90 7 209 41.8 16.5
0.5 ≤30 2.5 410 60 12 6 5-Φ10 16 95 30
1 ≤50 5 119 23.8 12
1.5 ≤75 7.6 179 35.8 18
1.75 ≤90 9 209 41.8 20.5
0.5 ≤30 3.2 510 60 12 7.5 5-Φ10 16 95 30
1 ≤50 6.4 119 23.8 15
1.5 ≤75 9.5 179 35.8 22
1.75 ≤90 11 209 41.8 26




Type:SN-MY07-A


type Load (kg) Speed
(m/s) 		Roping Rise(m) Motor Parameter Brake Parameter Sheave Parameter
Rated power
(kW) 		Rated Torque
(N.m) 		Rated Speed (RPM) Rated Frequency
(Hz) 		Rated Current
(A) 		Voltage
380V 		Current (A) Voltage (V) Braking Torque (N.m) nxd(mm) Pitch
(mm) 		β γ
MY07-630A/050P 630 0.5 2:1 ≤30 2 320 60 12 4.8 380 2.1 DC110 ＞1280 5-Φ8 12 95 30
MY07-630A/100P 1 ≤50 4 119 23.8 9.2
MY07-630A/150P 1.5 ≤75 6 179 35.8 14
MY07-630A/175P 1.75 ≤90 7 209 41.8 16.5
MY07-800A/050P 800 0.5 ≤30 2.5 410 60 12 6 6-Φ8 12 95 30
MY07-800A/100P 1 ≤50 5 119 23.8 12
MY07-800A/150P 1.5 ≤75 7.6 179 35.8 18
MY07-800A/175P 1.75 ≤90 9 209 41.8 20.5
MY07-1000A/050P 1000 0.5 ≤30 3.2 510 60 12 7.5 6-Φ8 12 95 30
MY07-1000A/100P 1 ≤50 6.4 119 23.8 15
MY07-1000A/150P 1.5 ≤75 9.5 179 35.8 22 7-Φ8
MY07-1000A/175P 1.75 ≤90 11 209 41.8 26



SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts 0

SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts 1

SN-MY07 Type Gearless Traction Machine For Hot Sale Elevator Lift Parts 2

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
