350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift

Large Image : 350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	SN-KA120D

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	$500~1200
Packaging Details:	Wooden box
Delivery Time:	7~15 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	5000pcs/month

Contact Now

350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift

Description

Name:	Gearless Machine	Load:	350kg~700kg
Speed:	0.25m/s-0.4m/s	Traction Ratio:	1:1
Static Load:	1500kg	Voltage:	220V/380V
Warranty Time:	12 Months	Application:	Elevator.lift
Model:	Gearless Machine	Type:	Gearless Machine

350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift

Quality direct drive machine PMS motor (Home lift application without counterweight design)

Load(P+Q):350kg~700kg	Voltage:220V/380V	IP Code: IP41
Speed:0.25m/s-0.4m/s	Brake Vol: DC110V	INS.Class: F
Roping:1:1	Static Load:1500kg	Poles: 32

SN-KA120D Series Direct drive Machine Drum Traction Machine Specification

Type	Load (P+Q) [kg]	Lift Speed [m/s]	Drum
Type	Load (P+Q) [kg]	Lift Speed [m/s]	Diam [mm]	Groove	Vol [V]	Power [kW]	Hoist height(M)	Speed [r/min]	Current [A]	Freq [Hz]	Poles
SN-KA120D	350	0.3	120	2×Φ6	380V	1.1	6-12	48	5	12.80	32
SN-KA120D	350	0.4	120	2×Φ6	380V	1.4	6-12	64	5	17.07	32
SN-KA120D	500	0.3	120	2×Φ6	380V	1.6	6-12	48	6	12.80	32
SN-KA120D	500	0.4	120	2×Φ6	380V	2.1	6-12	64	7	17.07	32
SN-KA120D	600	0.3	120	2×Φ6	380V	1.8	6-12	48	7	12.80	32
SN-KA120D	600	0.4	120	2×Φ6	380V	2.4	6-12	64	9	17.07	32
SN-KA120D	700	0.3	120	2×Φ6	380V	2.1	6-12	48	8	12.80	32
SN-KA120D	700	0.4	120	2×Φ6	380V	2.8	6-12	64	10	17.07	32

350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift 0

350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift 1

350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift 2

350kg~700kg Direct Drive Winding Drum Gearless Machine For Home Lift 3

Frequently Asked Questions

1. Are the elevator wire ropes durable?

The elevator wire rope has special provisions and requirements. Configuration considers not only wire rope and rated load, but also the size of the traction. The tensile strength exceeds the lift weight, with a safety factor of four or more wire ropes, preventing simultaneous breakage.

2. Is it dangerous during sudden power failure while the elevator is running?

In such cases, the elevator automatically stops due to electrical and mechanical safety devices. The brakes engage during power failure. Planned outages are preceded by prior notice from power supply departments.

3. Will users be hurt if the doors close suddenly?

The doors automatically reopen when touched during closing, with anti-pinch switches preventing closure. The closing force is carefully calibrated for safety.

4. How does the elevator operate?

Elevators move via counterweight wire ropes through traction drive, moving vertically along guide rails.

5. Is escalator installation complicated?

Our escalators feature integrated structures for precision and efficiency, enabling easier installation and more convenient commissioning.

6. Do you have any certifications?

Yes, we hold ISO9001, CCC, and CE Certificates for our products.
