320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine

Large Image : 320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine

Product Details:

Place of Origin:	China
Brand Name:	SUNNY
Certification:	CE,ISO9001
Model Number:	SN-KA100

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	$500~1200
Packaging Details:	Wooden box
Delivery Time:	7~15 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	5000pcs/month

Contact Now

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine

Description

Name:	Elevator Belt Drive Gearless Traction Machine	Load:	320kg~1000kg
Speed:	0.5~1.5 M/s	Traction Ratio:	2:1
Static Load:	1500kg	Voltage:	220V/380V
Warranty Time:	12 Months	Application:	Elevator.lift
Model:	Elevator Belt Drive Gearless Traction Machine	Type:	Elevator Belt Drive Gearless Traction Machine

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine

Quality elevator steel belt gearless traction machine with CE certificate

Load:320kg~1000kg	Voltage:220V/380V	IP Code: IP41
Speed:0.5~1.5 m/s	Brake Vol: DC110V	INS.Class: F
Roping:2:1	Static Load:5000kg	Poles: 16

SN-KA100 Series Direct drive Machine Drum Traction Machine Specification

Type	Load (P+Q) [kg]	Lift Speed [m/s]	Drum
Type	Load (P+Q) [kg]	Lift Speed [m/s]	Diam [mm]	Groove	Power [kW]	Torque(Nm)	Speed [r/min]	Current [A]-220V	Current [A]-380V	Freq [Hz]	Poles
SN-KA100	320	0.5	100	2×30-65	1.2	62	191	7	5	25.6	16
SN-KA100	320	1.0	100	2×30-65	2.5	62	382	9	6	51.2	16
SN-KA100	400	0.5	100	2×30-65	1.4	70	191	8	5	25.6	16
SN-KA100	400	1.0	100	2×30-65	2.8	70	382	10	7	51.2	16
SN-KA100	450	0.5	100	2×30-65	1.6	80	191	7	5	25.6	16
SN-KA100	450	1.0	100	2×30-65	3.2	80	382	12	8	51.2	16
SN-KA100	630	0.5	100	2×30-65 3×30-65	2.2	110	191	8	6	25.6	16
		1.0	100		4.4		382	15	9	51.2	16
		1.5	100		6.6		573	23	15	76.8	16
SN-KA100	800	1.0	100	3×30-65	5.4	135	382	19	11	51.2	16
SN-KA100	800	1.5	100	4×30-65	8.1	135	573	29	18	76.8	16
SN-KA100	1000	1.0	100	3×30-65	6.8	170	382	24	14	51.2	16
SN-KA100	1000	1.5	100	4×30-65	10.2	170	573	36	23	76.8	16

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine 0

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine 1

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine 2

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine 3

320kg~1000kg Elevator Belt Drive Gearless Traction Machine Steel Belt Traction Machine 4

Frequently Asked Questions

1. Are the elevator wire ropes durable?

The elevator wire rope has special provisions and requirements. Configuration considers not only wire rope and rated load, but also the size of the traction. The tensile strength exceeds the lift weight, with a safety factor of four or more wire ropes, preventing simultaneous breakage.

2. Is it dangerous during sudden power failure while the elevator is running?

In such cases, the elevator automatically stops due to electrical and mechanical safety devices. The brakes engage during power failure. Planned outages are preceded by prior notice from power supply departments.

3. Will users be hurt if the doors close suddenly?

The doors automatically reopen when touched during closing, with anti-pinch switches preventing closure. The closing force is carefully calibrated for safety.

4. How does the elevator operate?

Elevators move via counterweight wire ropes through traction drive, moving vertically along guide rails.

5. Is escalator installation complicated?

Our escalators feature integrated structures for precision and efficiency, enabling easier installation and more convenient commissioning.

6. Do you have any certifications?

Yes, we hold ISO9001, CCC, and CE Certificates for our products.
