Permanent Magnet Synchronous Gearless Traction Machine For Elevator

Permanent Magnet Synchronous Gearless Traction Machine For Elevator
Permanent Magnet Synchronous Gearless Traction Machine For Elevator Permanent Magnet Synchronous Gearless Traction Machine For Elevator

Large Image :  Permanent Magnet Synchronous Gearless Traction Machine For Elevator

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: CE,ISO9001
Model Number: SN-MCB200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Packaging Details: in Carton Box
Delivery Time: 7~15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs/month

Permanent Magnet Synchronous Gearless Traction Machine For Elevator

Description
Name: Gearless Traction Machine Load: 630~1150kg
Speed: 0.5~1.75m/S Votage: 380V
Weight: 370kg Roping: 2:1
Product Name: Elevator Parts Applicable: Elevator Equipment
Brake: DC110V 2x1.3A Material: Stainless Steel
Model: Gearless Traction Machine Type: Gearless Traction Machine
High Light:

Synchronous Gearless Traction Machine

,

Permanent Magnet Gearless Traction Machine

,

Elevator Gearless Traction Machine

Elevator Permanent Magnet Synchronous Gearless Traction Machine for elevator parts



SN-MCB200

Voltage 380V Roping 2:1
Load 630~1150kg Speed 0.5~1.75m/s
Sheave Diam 400/480mm Duty S5-40%
IP Code IP41 Max. Static Load 3000kg
Ins. Class F Weight 370kg
Brake DC110V 2x1.3A



DIMENSIONS

Permanent Magnet Synchronous Gearless Traction Machine For Elevator 0

SN-MCB100

Voltage 380V Roping 2:1
Load 320~800kg Speed 0.5~1.75m/s
Sheave Diam 320mm Duty S5-40%
IP Code IP41 Max. Static Load 2500kg
Ins. Class F Weight 210kg
Brake DC110V 2x1.3A



DIMENSIONS

Permanent Magnet Synchronous Gearless Traction Machine For Elevator 1



Permanent Magnet Synchronous Gearless Traction Machine For Elevator 2



Permanent Magnet Synchronous Gearless Traction Machine For Elevator 3



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
